Façade and sliding door systems of the highest quality

Solutions profiled to meet expectations

Today it is difficult to imagine building facades without large glazing. A glass facade adds lightness to the structure, optically enlarges the space, and provides a panoramic view. Achieving such spectacular effects would not be possible without the right technology. Its development has been in the hands of Yawal S.A. for 30 years.

The company is part of one of the largest aluminum groups in Central and Eastern Europe. It offers systems for the production of, among others, windows, doors, facades and terrace doors. The company's products are characterized by the highest quality, confirmed by technical approvals of the Building Research Institute and tests determining their compliance with European standards.

Façade systems and sliding door systems of the highest quality

© YAWAL

SELECTED FACADE SYSTEMS

• FA 50N - The system enables the design and construction of lightweight mullion and transom curtain walls. It is classified among the best curtain walls available on the market.
• FA 50N HI - A system with the highest thermal insulation properties. Modern and at the same time energy efficient, with very high water and wind resistance. Ideal for use in office and public buildings. The unique system of foam insulator and the possibility of using double glazing allows to obtain excellent parameters.
• FA 50N SL - The system is used to make structures that form a flat surface from the outside. It combines the advantages of a classic mullion and transom facade with the aesthetic appearance of a structural facade.
• FA 50N SW - Structural window system. It is of a universal nature, which allows the construction of a parallel sliding, swinging or casement window in the facade, with mechanically or structurally fixed glazing.
• FA 50N RW - A system that allows the construction of modern roof windows installed in skylights, roofs and conservatories built on the basis of FA 50N and FA 50N SLfacades. It ensures optimum ventilation of rooms, supplying large amounts of fresh air. It is distinguished by the highest performance parameters on the market. It is characterized by excellent thermal insulation and high airtightness achieved through a new EPDM central gasket and three condensate drainage lines.
• FV 50N INV - A modern system for making windows embedded in the supporting grid of the FA 50N and FA 50N SL mullion and transom curtain wall. It gives the possibility to construct windows opening to the inside of the curtain wall with tilt and turn, tilt and turn or tilt function. A characteristic feature of the system is that the frame and window sash are invisible on the outside of the curtain wall.

SELECTED WINDOW AND DOOR SYSTEMS WITH THERMAL INSULATION

• TM 102HI - System dedicated to passive and energy-efficient construction. It meets the highest requirements in terms of strength, quality and aesthetics of the shaped objects. Significantly reduces the access of cool air to the interior of the building in winter, and protects it from excessive heating in summer.
• TM 77HI - Thanks to the use of spacers between the aluminum profiles, excellent parameters of thermal insulation, acoustic insulation, safety and protection against wind and water were obtained. The role of thermal insulation is fulfilled by chambered thermal insulators with filling.
• TM 74HI - A system based on reinforced profiles in both external and internal arrangement. It allows the creation of structures of large dimensions. The thermal insulators used in it are made of fiberglass-reinforced polyamide, and the space between them is filled with polyurethane foam.

Façade systems and sliding door systems of the highest quality

© YAWAL

SELECTED SLIDING DOOR SYSTEMS

• MOREVIEW - A system of large-size sliding doors with slim profiles completely hidden in the floor, walls and ceiling. Moreview gives the possibility to construct doors with a maximum height of up to 4 m and a maximum weight of the sliding leaf of up to 1200 kg. The aesthetics of the construction are supported by, among other things, the visible width of the mullion at the descent of the wings of only 27 mm. The innovative design allows the installation of glass panes side by side without aluminum elements visible from the outside. The static mullion makes it possible to create a sequence of fixed glazing, and the all-glass corner allows them to be joined at any angle.
• DP SLIDE - A modern system of thermally insulated sliding and lift-and-slide doors. The system has 2 variants of installation depth: DP 86 and DP 110. Excellent thermal insulation is achieved by using thermal breaks exactly in the plane of the glazing and by dividing the construction zones into: warm (thermally insulated) and cold (uninsulated). DP Slide ensures easy installation and servicing of structures built on its basis.
• DP 180 - System with several variants of doorframes (fixed, two- and three-way). It guarantees excellent thermal insulation parameters. Around the perimeter of the doorframe, an insulating profile made of HPVC is used. The DP 180 sliding sash opens automatically. The entire drive system is invisible. Thanks to built-in batteries, the automatic operates even in the event of power failure. The handle in this solution is replaced by a touch panel. The door can be opened and closed using a remote control, fingerprint reader, code keypad or smartphone.
• DP 150T - Allows the construction of lift-and-slide doors with a height of up to 3,300 mm and a leaf weight of up to 430 kg. Often used as terrace exits or doors in conservatories.

Facade and sliding door systems of the highest quality

© YAWAL

SELECTED WINDOW AND DOOR SYSTEMS WITHOUT THERMAL INSULATION

• PBI 84 OFFICE - The system is designed for the construction of interior walls and open space development. The solution gives the possibility to install fillings of a wide range of thicknesses (glass from 6 to 12 mm, opaque fillings from 12 to 18 mm), while maintaining 38 mm width of the structure visible from the outside.
• PBI 50N - The system is used to make partitions and structures for interior development that do not require thermal insulation. The depth of the profile (50 mm) makes it one of the strongest on the market in this group.

SELECTED FIRE PROTECTION SYSTEMS

• TM 75EI - The system for making fire-resistant walls and doors with fire resistance classes from El 30 to El 60. It also makes it possible to make smoke-proof structures.
• TM62EI - The system is used to make a wide range of fire-rated walls and doors with a fire resistance class of EI 30. The role of insulation in the profiles is fulfilled by thermal breaks made of glass fiber-reinforced polyamide.
• TM 90EI YAWAL FIRE BLOCK 120 - The system is used to make a wide range of fireproof building partitions with fire resistance class EI 120.

For more information, visit the company's YAWAL S.A. page on the A&B portal.
