Aluprof energy-efficient aluminum systems
In Poland, more than 250 new buildings are built each year using Aluprof aluminum systems. The company offers products that perfectly meet the requirements of green building, which work well in both commercial and private construction.
Why are these systems so popular?
MB-104 Passive System of passive windows and doors
The MB-104 Passive system of windows and doors with a thermal barrier, in SI and Aero variants, with the highest thermal insulation, meets all the requirements for elements used in passive construction. The system is used to make: various types of windows, doors, vestibules, showcases and spatial structures, which are characterized, in addition to excellent thermal insulation (for UW opening window from 0.53 W/m²K), also by very good sound insulation, water and air tightness and high structural strength.
The parameters of windows made from MB-104 Passive system elements exceed the current requirements of the strictest applicable regulations and standards, which is why MB-104 Passive is a system dedicated to energy-efficient and passive construction, as confirmed by the Passive House Institute Darmstadt certificates obtained for the MB-104 Passive SI and MB-104 Passive Aero versions.
Aluprof energy-efficient aluminum systems
© ALUPROF
MB-86 Window and Door System
MB-86 is an innovative window anddoor system and the first in the world to use aerogel, a material with excellent thermal insulation. Three construction variants(ST, SI and AERO) guarantee the choice of the best solution, corresponding to the requirements and needs of users. In addition, the system is characterized by high strength profiles, which allows to make windows of large size and weight. It also has a two-component central gasket, increasing the thermal insulation of the space between the sash and the frame. Profile shapes are adapted to the installation of various types of perimeter fittings, including concealed hinges. At the same time, a wide range of glazing allows the use of all common types of glass (including two- and three-chamber glass, acoustic or burglar-proof). Thermal insulation UW from 0.72 W/m2²K. The system meets the requirements of passive and energy-efficient construction.
MB-79N Window and Door System
The MB-79N system is the latest product in ALUPROF's window and door system range. It is the successor to the very popular and widely used MB-70 system in the construction industry, introduced to meet increased thermal insulation requirements from 2021. It is used to make a wide range of constructions, which include various types of windows and doors, as well as showcase solutions with doors.
MB-TT50 Facade with high thermal insulation performance
MB-TT50 facade is the latest technologically advanced aluminum system with mullion and transom construction. It allows the construction of curtain or infill walls, roofs and spatial structures. Thanks to the use of a set of matching insulators, the facade guarantees a high level of protection of the building against heat loss, and their special shape facilitates the prefabrication of the facade at the same time. In addition, a set of gaskets and a 3-level cascade drainage and venting system ensure proper functioning of the facade even in the most adverse weather conditions. The MB-TT50 system is certified by the PHI Darmstadt Institute in the highest class A+, which is a confirmation that the constructions made with it can be used in the construction of passive buildings (Thermal insulation of the system Uf from 0.5 W/m²K).This system has already been successfully installed in several domestic and foreign facilities, including: Estonian Technological University in Tallinn, The Apex in London or Alchemy in Gdansk.
Aluprof energy-efficient aluminum systems
© ALUPROF
MB-SR50N HI+
The facade with very good technical parameters is designed for the construction and execution of light curtain walls of hanging and filling type, as well as roofs, skylights and other spatial structures. In order to achieve optimal thermal and acoustic insulation and facilitate the installation of the facade, the MB-SR50N HI+ system uses an insulator made of PE material, which gives very good thermal insulation (Uf from 0.59 W/m²K), and its shape ensures the proper guidance of the screw during the glazing of the facade. This has a huge impact on the speed and simplicity of installation. The system makes it possible to build facades with visible narrow dividing lines, while ensuring the durability and strength of the construction. The advantages of the MB-SR50N HI+ system include: angular connections that allow free shaping of aluminum buildings, mullions and transoms with "sharp" edges that allow the construction of facade load-bearing structures with the appearance of a uniform truss, aesthetic varieties of facades and a number of overlay profiles of different shapes provide many variants of the facade image, a wide range of opening elements in the facade: various types of windows and doors, including MB-SR50N RW skylight windows integrated into the facade, as well as MB-SR50N OW hinged and parallel opening windows.
MB-77HS Lift-and-slide doors
The construction of the profiles allows exclusive large-size doors to be made (sash weight up to 600 kg), filled with one-, two- or three-chamber glass, and the materials and technical solutions used help achieve a high degree of thermal and acoustic protection. Thanks to its properties, the system is ideal for both single-family buildings and comfortable apartments or hotels. In addition, the closed shape of the glazing bars and anti-burglary details make it possible to achieve increased anti-burglary properties. MB-77HS doors allow the construction with a low threshold, with a narrow mullion width of only 47.5 mm, as well as 90 and 270 degree corner doors with a movable mullion. Lift-and-slide doors provide a convenient exit to a balcony, terrace or garden space. It is possible to make 90 and 270 degree corner doors with a movable post. A wide range of colors allows you to match the door to the decor of the environment.
Aluprof energy-efficient aluminum systems
© ALUPROF
MB-SKYLINE Sliding door system
with a concealed frame
The MB-SKYLINE sliding door system is based on narrow profiles, which give the structures a modern and minimalist look. The narrow frames are hidden in the walls, floor and ceiling and the wings are flush with the frame profile on the sides. The visible width of the connection of the door wings is only 25 mm. The whole is an almost uniform glazing with delicate dividing lines. Doors made in this way give the building a unique style, perfectly fit into the trends of luxury construction and thus raise the status of the entire investment. In addition, the system allows the use of doors up to 4 meters high, which, with a maximum leaf weight of 750 kg, provides many opportunities for designers and allows to achieve spectacular glazing.
Aluprof system models for BIM design are available at www.architekci.aluprof.eu.
