Efficient temperature and microclimate control?
Only with fans from Uniwersal
Uniwersal includes several high-tech devices that help control the microclimate in a destination. There are different versions of the devices to choose from, ranging from classic DA fans to integrated vents to hybrid cowls.
DA roof fans
They are made of polyester-glass or vinyl-ester-glass composite. It is a resin reinforced with fiberglass. Thanks to its properties, it provides structures with durability and resistance to weathering.
The rotor is dynamically and statically balanced, and can operate at temperatures up to 45°C as standard, or up to 90°C in special versions.
WZ type integrated ventilators
Hybrid design, whose operation depends on external factors. It works mechanically and naturally or alternately. Responsible for its reliability are control elements that monitor external conditions and the operating parameters of the entire system.
WZ Integrated Ventilator
© UNIWERSAL
WZ/DA integrated ventilators are ventilation units installed on a single exhaust opening. They perform the function of a gravity ventilation ventilator - screened, activated manually or on a signal emitted from an internal sensor.
Quiet-running fan SZTIL
On the inside they have a sound-insulating dome. SZTIL fans operate quietly, and the dome itself in them acts as a screen for the rain jamming. Moisture does not get inside.
The products are made of polyester-glass composite. This means that they work for a long time, trouble-free and with low sound pressure. Their advantages also include durability and the fact that in terms of form, color and application they can be easily adapted to the architecture of the building.
FEN fan
Economical device made of polyester-glass composite. They are resistant to damage and atmospheric factors, easy to repair and maintain. FEN fans can operate in environments with temperatures up to 45°C.
BRYZA gravity ventilator
A ventilation cowl crowning a gravity duct. It was created based on Schiedel hollow blocks. The cowl uses the force of the wind, so that gravitational air movement is generated in the ventilation channel. The efficiency of the Breeze compared to the classic Zephyr is better by about 10-30%. The cowl has a modified shape and dimensions, and fits single-row chimneys made of ventilation blocks. It was created from weather-resistant polyester-glass laminate and is dyed in any color.
Fenko hybrid cowl
Reliable ventilation in single-family buildings? Only with the Fenko hybrid cowl, which allows to achieve optimal values of gravitational draught in the ventilation ducts of buildings. It is installed on the top of the ventilation chimney and works when weather conditions allow.
Fenko hybrid cowl
© UNIWERSAL
With the fan, 150 m 3 /h can be extracted from the room in the case of the first gear and 210 m 3 /h for the second gear of the motor rotation. It works quietly, with sound pressure levels equal to 33 dBA and 41 dBA. The fan included an electronically commutated motor, which affects the low power level (9.5/6.2).
MAG hybrid cowl
MAG fan fits for installation in residential and single-family buildings, especially in TBS technology. It combines the functions of mechanical ventilation and gravity ventilation. The hybrid is available in two versions: with a capacity of 600 m 3 /h and 400 m 3 /h. The two-pole motors consume low power - 27 Watts in the first case and 16 Watts in the second. The inlet diameter of the hybrid cowl is Ø200mm, it fits ventilation chimneys and PVC ducts, spiro ducts, stainless steel and galvanized steel sheets. It produces low sound pressure, that is, it works quietly.
MONSUN Integrated Ventilator
Monsun ventilators are a combination of mechanical ventilation and gravity ventilation. They are constructed of polyester and glass. In their interior, a fan with a channel ending in a mounting flange is centrally mounted. It can be connected to eaves or extraction. Ventilation is carried out with just one opening in the roof.
Products are suitable for use in rooms where constant natural ventilation must be maintained in the fight against heat loss and moisture formation.
